210l 2.88mpa Liquid Nitrogen Dewar Tank Cryogenic Dewar Flask For Welding

Short Description:

210l 2.88mpa Liquid Nitrogen Dewar Tank Cryogenic Dewar Flask For Welding Product Application DPL series dewar cylinder is a kind of high-performance vacuum insulated cylinder, which is used to store and transport cryogenic liquid oxygen, nitrogen, argon, carbon dioxide, liquefied natural gas ,etc. It can be used for road transportation of cryogenic liquid, and also can be used for on-site storage and supply. Long storage time, wide range of applications . P...


  • Place of Origin: China
  • Shipping: By sea
  • Product Detail

    Product Tags

    210l 2.88mpa Liquid Nitrogen Dewar Tank Cryogenic Dewar Flask For Welding

    Product Application

    DPL series dewar cylinder is a kind of high-performance vacuum insulated cylinder, which is used to store and transport cryogenic liquid oxygen, nitrogen, argon, carbon dioxide, liquefied natural gas ,etc. It can be used for road transportation of cryogenic liquid, and also can be used for on-site storage and supply. Long storage time, wide range of applications .

    Product Paramenters
    Specifications
    Product model
    DPL450-210-1.37
    DPL450-210-2.05
    DPL450-210-2.88
    volume(L)
    210
    210
    210
    Effective volume(L)
    189
    189
    189
    Size(D×H)mm
    Φ508×1716
    Φ508×1716
    Φ508×1716
    Working Pressure(MPa)
    1.37
    2.05
    2.88
    Set pressure of main safety value(MPa)
    1.59
    2.41
    3.45
    Set pressure of bursting discset(MPa)
    2.6
    3.6
    5.17
    Evaporation rate (Liquid nitrogen)
    ≤2.0%
    ≤2.0%
    ≤2.0%
    Empty weight(kg)
    131
    153
    173
    Maximum filling weight:Liquid oxygen(kg)
    215
    215
    215
    Maximum filling weight:Liquid nitrogen(kg)
    153
    153
    153
    Maximum filling weight:Liquid argon(kg)
    264
    264
    264
    Maximum filling weight:LNG(kg)
    80
    Level gauge
    Float type,

    Capacitance
    Float type,

    Capacitance
    Float type,Capacitance
    The base style
    Stainless steel-rubber bas
    Stainless steel-rubber bas
    Stainless steel-rubber bas
    Details Images
    Packing & Delivery
    Packaging and delivery
    1.packaging with nude
    2.packaging with wooden pallets
    3.packaging as you required
    Delivery Time: About 30 days after receipt of the deposit.
    Company Profile
    Xinxiang Chengde Energy Technology Equipment Co., Ltd. (original Chengde Gas Equipment Co., Ltd.) was founded in 2002, company is located in Industrial Park, Fengquan district, Xinxiang city, Henan province. with its south to the yellow river and north to Taihang Mountain, with beautiful scenery and convenient transportation. The company has been committed to the pressure vessels, Low-temperature cryogenic equipment and gas equipment in the field of research and development, design, manufacture and installation.
    The company more than 30,000 square meter for workshop.Our company have exported products to foreign countries more than 19 years ,have rich experience in production and exported ,products have exported to more than 35 countries ,also have branch office in the Vietnam.
